Jaguar I-Pace Battery Disconnector Rotary Switch

The rotary battery disconnector switch from a Jaguar I-Pace pack. The manual isolator built into the battery, used to break the high voltage circuit by hand before anyone works on it.

Every high voltage pack needs a point where a person can isolate it themselves and see that it is isolated. On the I-Pace that job is done by this rotary switch, mounted on the pack. Turning it breaks the circuit mechanically, which is a different kind of assurance from a contactor commanded open by software.

For anyone building with I-Pace modules, or repairing an I-Pace pack, this is the original part rather than a substitute.

Confirm the fit before you order. This is a vehicle specific part and we have no drawing or datasheet published for it. If you are designing it into something other than an I-Pace pack, ask us for the dimensions, the contact rating and the terminal arrangement first.

Key specifications

Features

• Genuine vehicle part rather than a generic substitute
• Manual, mechanical isolation that is obvious by inspection
• Rotary action, which is harder to operate accidentally than a pull handle

Compatibility

For Jaguar I-Pace battery packs, in repair or in conversions built around I-Pace modules.

Ask us before designing it into anything else. No dimensioned drawing, contact rating or terminal detail is published for this switch, and those are the three things you would need.

Isolation is not the same as safe. Opening a disconnector separates the pack, but capacitance downstream can hold a charge. Follow a proper isolation and proving procedure before touching anything.

In the box

• 1 x rotary battery disconnector switch

Downloads

No document is published for this switch. Contact us for dimensions, contact rating or terminal arrangement.
