An Amphenol Industrial HVSL1200 RADSOK high voltage plug. A single pole connector built around Amphenol's RADSOK contact system.
RADSOK is the reason to choose this connector. A conventional contact grips a pin at a few points, so the current crowds through those points and everything else about the joint follows from that: resistance, heat, and how much the contact degrades every time it is mated. A RADSOK contact is a stamped lattice that wraps the pin with hundreds of contact points distributed around its whole circumference.
What that buys you is low resistance at high current, and it keeps buying it. Less contact resistance means less heat at the joint, which is usually what limits a high voltage connector's continuous rating. It also means insertion force stays low while contact quality stays high, so the connector survives being mated and unmated far more often than a conventional one.
HVSL1200 is the larger end of the range, which is why it carries a price to match. This is a connector for a main power path rather than an auxiliary.
Confirm the ratings before you design it in. We have no datasheet published here, and the HVSL1200 series covers several contact sizes and cable ranges. Ask us for the current rating, the contact size and the conductor range this one accepts.
Key specifications
| Manufacturer part | Amphenol Industrial HVSL1200062A195 |
|---|---|
| Family | HVSL1200, RADSOK contact system |
| Type | High voltage plug |
| Poles | 1 |
| Weight | 0.4 kg |
Features
- RADSOK contact, with hundreds of contact points around the pin's circumference
- Low contact resistance, so less heat at the joint at high continuous current
- Low insertion force despite high contact quality, so it tolerates repeated mating
- Amphenol Industrial, a production grade high voltage family
Compatibility
For high voltage main power connections in EV, energy storage and industrial systems.
Single pole means one connector per polarity, so positive and negative cross independently and can be placed apart from each other. Plan a keying or physical separation convention so the two cannot be interchanged.
Ask us for the ratings and the mating half before specifying it. See the note above.
In the box
- 1 x HVSL1200 RADSOK plug
Downloads
No document is published here. Amphenol Industrial publish the HVSL1200 series data and we can point you to it.
