LDU 23-Pin Data Board
Terms and Conditions
Orders Dispatched Within 24 hours - Excluding Weekends and Bank Holidays.
A replacement 23 pin data interface board for a Tesla large drive unit, for when the unit arrives with its data connector damaged.
Salvaged drive units rarely come out of a car gently. The 23 pin data connector is small, exposed, and one of the first things to get broken during removal or transport. Until now that meant a drive unit that was mechanically perfect and electrically unusable, because there was no way to get signals into it.
This board replaces that connector, so a damaged unit becomes a usable one.
Read this before ordering. It works only with an aftermarket large drive unit inverter board. It will not work on a drive unit running its original Tesla logic, and it is not a repair for a standard application. If you are not replacing the inverter control board as well, this part will not help you.
Key specifications
| Part | LDU23DB |
|---|---|
| Type | 23 pin data interface board |
| Fits | Tesla large drive unit |
| Requires | An aftermarket large drive unit inverter board |
| Weight | 0.05 kg |
Features
- Recovers a drive unit whose data connector was damaged in removal
- Direct replacement for the 23 pin interface
- Pairs with the matching replacement loom
Compatibility
For a Tesla large drive unit running an aftermarket inverter control board.
It will not work on a drive unit using its original Tesla logic board. That is the single thing to check before ordering, and it is not a limitation we can work around.
The matching replacement loom is a separate part and is usually wanted at the same time.
In the box
- 1 x 23 pin data interface board
Downloads
No document is published for this board. For the pinout or to confirm it suits your setup, contact us.
